Home > Products > RJ45 USB Connector

Products

RJ45 USB Connector

Single Port USB B Female Connector Tab Up Without Transformer

  • Single Port USB B Female Connector Tab Up Without Transformer

Product Details:

Place of Origin:
Shen Zhen, China
Brand Name:
OEM/ODM
Certification:
ISO9001 : 2008 , SGS , RoHs , UL
Part Number:
RJ45-USB-027




Payment & Shipping Terms:

Packaging Details:
60 pcs in 1 tray , 1320pcs in 1 carton
Delivery Time:
1-2 Weeks
Payment Terms:
L/C, D/A, D/P, T/T
Supply Ability:
50000/day




Download

Inquiry

Detailed Product Description

Single Port RJ45 USB Connector Tab Up Without Transformer for Network Switch, G / Y

Feature:
1.Complies with IEEE standards and all 10/100 Ethernet specifications including 350uH with
8MA DC bias
2.Contact:Phosphor Bronze, 6u-inch gold flashed unless specified

1.Housing:Thermoplastic LCP UL94V-0 rated
2.Operating Temperature:0℃ --70℃
3.Storage temperature:-40℃--85℃

Peak reflow temperature rating 245℃
1.Minimum1500Vrms isolation per IEEE 802.3requirement

Electrical Specifications:

1.Turns Ratio: TX & Rx+1:1±5%
2.Insertion Loss:1-30MHz:-1.0dB Max
3.Return Loss:1-30MHz:-16dB Min; 60-80MHz:12dB Min
4.Common Mode Rejection:1-100MHz:-30dB Min;200MHz:-20dB Min
5.Crosstalk:1-100MHz:-30dB Min
6.OCL:100KHz,0.1V,8MADC:350uH Min
7.Hi-Pot:1500VAC,1mA,1Sec
