2.54MM Pitch Female Pin Headers Connector, 40 Pin Header DIP Dual 90 Degree For PCB

< >

Product Details:

Place of Origin:	Shen Zhen, China
Brand Name:	OEM/ODM
Certification:	ISO9001 : 2008 , SGS , RoHs
Part Name:	Pin Header

Payment & Shipping Terms:

Packaging Details:	20pcs in 1 tray
Delivery Time:	7 - 10 Work Days
Payment Terms:	L/C, D/A, D/P, T/T
Supply Ability:	5,000,000 PCS / Month

Detailed Product Description

2.54MM Pitch Female Pin Headers Connector DIP Dual 90 Degree For PCB

Specifications

Gender :	Female
Pin :	Round, Tin / Gold plate
Layer :	Dual/double
Number of Row :	single, double
Orientation :	Vertical, Right angle
Termination :	Through hole, DIP, SMT

Material:
1. Housing Material: Glass Filled Polyester(UL94V-0),NYLON, LCP
2. Contact Material: Phosphor Bronze
3. Plating: Contact Area-Selecting Gold Plating.
4. Cap: Glass Filled Polyester(UL94V-0),NYLON, LCP

Electrical:
Current Rating 1 AMP
Voltage Rating 1.25 VAC
Insulation Resistance 1000MΩMin
Withstanding Resistance 500VAC
Contact Resistance 20mΩMax

Environmental:
1. Storage Temperature -40°C~105°C Relative Humidity <80%.
2. Operation Temperature -40°C~+105°C
Lead-free process, compliant RoHS
