1055-206019 90 Degree RJ11 6P6C Single Port Tab Up With Shielded

Product Details:

Application :	Networking products: NIC, HUB, Switch, Router, Bridge. Station: PC/system, Printer, Server, NB, IA Cable Modem, XDSL application, Set-Top-Box, Camera, Computer.
Gold Plated :	Fu" , 1u" , 3u" , 6u" , 15u" , 30u" , 50u"
Main Products :	Carjack , RJ45 Jack , RJ45 Connector , RJ45 , Rj45 Socket
OEM/ODM:	OEM Service Offered Design Service Offered Buyer Label Offered
Gender :	Female
Project Application :	Networking Solutions
Port :	Single Port

ELECTRICAL:

1. VOLTAGE RATING:125 VAC RMS.

2. CURRENT RATING:1.5 AMP.

3. CONTACT RESISTANCE:50 milliohms max.

4. INSULATION RESISTANCE:500 me ohms min @ 500V DC.

5. DIELECTRIC WITHSTANDING

RESISTANCE:1000V AC RMS 50Hz. 1min.

MECHNICAL:

1. HOUSING MATERIAL: glass filled polyester(UL94V-0).

2. CONTACT MATERIAL: phosphor bronze T=0.46mm (C5 100).

3. PLATING: gold plating over nickel.

4. DURRABILITY:750 cycles min.

5. PCB RETENTION PRE-SOLDER:1 LB min.

6. PCB RETENTION POST-SOLDER:10 LB min.

ENVIRONMENTAL:

1. STORAGE: -40℃ TO +85℃.

2. OPERATION:0℃ TO 70℃

3. WAVE SOLDER TEMPERTURE:230-250℃ (5-10 seconds)
