Place of Origin:
|
Shen Zhen, China
|
|
Brand Name:
|
OEM / ODM
|
|
Certification:
|
ISO9001,SGS,UL,CE,REACH
|
|
Part Number:
|
RJ45-392G-160F13-22
|
|
Packaging Details:
|
10 pcs in 1 tray
|
|
Delivery Time:
|
3-30 work days
|
|
Payment Terms:
|
T/T, L/C, D/A, D/P, PAYPAL
|
|
Supply Ability:
|
2,000,000pcs/Month
|
RJ45 Connector Product Details:
|
Application :
|
TV , Set Box , IP CAMER , DVR, VOIP , Computer
|
|
Port :
|
8 Port
|
|
Plastic :
|
PBT
|
|
Shield Material :
|
Brass Alloy
|
|
Application :
|
8 Port 10/100/1000 Base-T
|
|
Terminal :
|
Phosphor Copper
|
|
Led :
|
Yellow, Green
|
|
1.Complies with IEEE standards and all 10/100 Ethernet specifications including 350uH with 8MA DC bias
|
|
|
2.Contact:Phosphor Bronze, 6u-inch gold flashed unless specified
|
|
|
Housing :
|
Thermoplastic LCP UL94V-0 rated
|
|
Operating Temperature :
|
0℃ --70℃
|
|
Storage Temperature :
|
-40℃--85℃
|
|
Peak reflow temperature rating 245℃
|
|
|
1.Minimum1500Vrms isolation per IEEE 802.3requirement
|
|
|
Turns Ratio :
|
Tx & Rx+1:1±5%
|
|
Insertion Loss :
|
1-30MHz:-1.0dB Max
|
|
Return Loss :
|
1-30MHz:-16dB Min; 60-80MHz:12dB Min
|
|
Common Mode Rejection :
|
1-100MHz:-30dB Min;200MHz:-20dB Min
|
|
Crosstalk :
|
1-100MHz:-30dB Min
|
|
OCL :
|
100KHz,0.1V,8MADC:350uH Min
|
|
Hi-Pot :
|
1500VAC,1mA,1Sec
|
|
Lead-free process, compliant RoHS
|
|
